AFFF Foam

CLASS B FIRE PROTECTION

AFFF Firefighting Foam for Hydrocarbon Fuel Fires

LCF AFFF foam concentrate (Aqueous Film-Forming Foam) is designed for Class B hydrocarbon fuel fires involving gasoline, diesel and other petroleum fuels. Its film-forming action helps suppress fuel vapours and control fire spread, supporting fire protection applications in oil storage facilities, refineries, airports and marine terminals.

Available in 1%, 3% and 6% grades, our firefighting foam concentrate offers options for different project requirements. We help you select the appropriate grade, review foam system compatibility and obtain product-specific technical documentation.

Freshwater & Seawater Compatible

Suitable for firefighting systems using either fresh water or seawater, making it ideal for marine, offshore and coastal applications.

Foam System Compatible

Suitable for foam monitors, foam chambers, sprinkler systems and proportioning systems.

Flexible Concentration Options

Available in 1%, 3% and 6% concentrations to meet different firefighting system requirements.

AFFF Application for Aircraft Fuel Fires
AFFF Application for Damaged Storage Tanks
AFFF Application for Derailed Fuel Wagons
AFFF Application for Diesel Bus Engine Fires
AFFF Application for Road Tanker Accidents
AFFF Application for Workboat Diesel Fires

Choose the Right Foam Concentrate

Match your foam concentrate to the fuels you handle, the equipment you use, and the conditions on site. Use this checklist to guide your selection.

  • Identify your fuels, including any alcohols, polar solvents, or fuel blends.
  • Define the areas to be protected and whether you’ll use fixed systems or mobile firefighting equipment.
  • Check that product testing and approvals cover your fuels and intended application.
  • Confirm that the proportioning ratio and viscosity are compatible with your proportioning and discharge equipment.
  • Verify suitability for your water supply, storage temperatures, and operating conditions.
  • Review local fire protection requirements, PFAS restrictions, and disposal requirements for spent foam solution.
  • Plan for storage, periodic testing, and replenishment. Check system cleaning requirements when replacing an existing foam concentrate.

Multi-Industry Fire Foam Solutions

Our foam concentrates are formulated for complex environments, including petrochemical, aviation, marine, and chemical storage. We provide standardized fire protection for various combustible liquid hazards.

  • power industry

    Protecting Critical Power Facilities

  • chemical industry

    Foam Solutions for Chemical Fire Risks

  • petroleum industry

    Foam Protection for Oil Storage and Processing

  • manufacturing industry

    Fire Safety on the Factory Floor

  • construction-industry

    Fire Protection for Construction Sites

  • transportation industry

    Fire Protection Across Transport Operations

From application to specification

Give your technical team the context they need to evaluate a concentrate.

01

Define the fuel & fire scenario

Hydrocarbon, polar solvent, combustible solid or battery hazard?

02

Check the equipment & water supply

Review proportioning, discharge equipment, water type and operating temperature.

03

Confirm the product documentation

Request current technical data, safety data and relevant application approvals.

Technical Specifications

Physical properties, recommended storage conditions, and fire performance data for 1%, 3%, and 6% AFFF concentrates.

ParameterAFFF 1%AFFF 3%AFFF 6%
AppearanceLight yellow transparent liquidLight yellow transparent liquidLight yellow transparent liquid
PH value6.0–9.56.0–9.56.0–9.5
Specific gravity (20°C)1.074 ± 0.01 g/mL1.021 ± 0.01 g/mL1.014 ± 0.01 g/mL
Freezing point−5°C (adjustable)−6°C (adjustable)−12°C (adjustable)
Recommended storage temperature−5°C to 45°C−6°C to 45°C−12°C to 45°C
Surface tension (mN/m)17.2 ± 10%20 ± 10%17.2 ± 10%
Interfacial tension (mN/m)2.8 ± 1.02 ± 1.02.4 ± 1.0
Foam expansion (20°C)6.5 ± 1.0 or 20%8 ± 1.0 or 20%6.1 ± 1.0 or 20%
25% drainage time (20°C)1.9 (1 ± 20%) min2.5 (1 ± 20%) min2.9 (1 ± 20%) min
Extinguishing time≤ 3 min≤ 3 min≤ 3 min
25% fire-resistance time≥ 10.0 min≥ 10.0 min≥ 10.0 min

Let’s Talk About Your Foam Needs

Get foam recommendations, pricing and supply options tailored to your project and budget.

  • Product Selection

Explore foam options for your application.

  • Project Quotations

Tell us your quantity and delivery destination.

  • Technical Information

Request product data and system compatibility details.
